Характеристики
| Параметр |
Значение |
| Производитель: |
Sony |
| Совместимый бренд: |
Sony |
| Совместимая модель: |
PXW-X160, PMW-200, PMW-100, PMW-160 |
| Compatible Model 2: |
HXR-NX5R, HXR-NX80, HXR-NX100 |
| Compatible Model 3: |
PXW-Z200, PXW-Z90, PXW-Z190 |
| Compatible Model 4: |
FX9, FS7 II, PXW-FS7, PXW-FS5, FS5 II |
| Compatible Model 5: |
DWT-P30/B |
| Connectivity: |
Wired, XLR-3-12C (x2) |
| Country of Origin: |
Japan |
| Diaphragm Size: |
Electret Condenser |
| Dimensions: |
φ24 × 137 mm (φ0.94 × 5.4 in) |
| Dynamic Range: |
100 dB or more |
| Особенности: |
MS Stereo system captures full stereo soundfield |
| Features 2: |
Monaural mode: disconnect R channel cable |
| Features 3: |
Integrated cable + balanced XLR connectors |
| Features 4: |
Compact 137 mm (5.4 in) body, low lens intrusion |
| Features 5: |
Wide operating temp: -20°C–60°C (-4°F–140°F) |
| Form Factor: |
Compact |
| Frequency Response (Mono): |
70–20,000 Hz |
| Frequency Response (Stereo): |
80–20,000 Hz |
| Item Weight: |
160 g (5.6 oz) |
| Maximum SPL: |
125 dB SPL or more |
| Модель: |
ECM-MS2 |
| MPN: |
ECM-MS2 |
| Output Impedance: |
30 Ω ±20%, Balanced |
| Output Terminal: |
XLR-3-12C × 2 |
| Polar Pattern: |
Cardioid (Unidirectional) |
| Power Consumption (Mono): |
3 mA or less |
| Power Consumption (Stereo): |
3 mA or less × 2 ch |
| Power Supply: |
DC 40–52 V (IEC61938 P48, Phantom) |
| Self-Noise: |
25 dB SPL or less |
| Sensitivity (Mono): |
-36 dB (0 dB=1V/Pa, 1 kHz) |
| Sensitivity (Stereo): |
-32 dB (0 dB=1V/Pa, 1 kHz) |
| Signal-to-Noise Ratio: |
69 dB or more (IEC 179 A-weighted, 1 kHz) |
| Stereo System: |
MS Stereo |
| Suitable For: |
Camcorder Recording, Broadcast, Film Production |
| Transducer Type: |
Electret Condenser |
| Тип: |
Condenser Microphone |
| Unit Quantity: |
1 |
| Unit Type: |
Unit |
| Wind Noise (with Windscreen): |
45 dB SPL or less |
| Wind Noise (without Windscreen): |
65 dB SPL |
| Универсальный товарный код: |
4905524846119 |
